The Magnum ME 2000W represents a cost-effective modified sine wave inverter optimised for mobile and RV applications where power density matters more than audio-grade precision. This compact, rugged unit combines inverter and charger functions, with a three-stage temperature-compensated charging profile that adapts to ambient conditions.

Installation is straightforward: connect inverter output to your distribution panel, link shore power to the terminal block, attach battery cables, and activate. The power factor corrected charger integrates seamlessly into existing wiring.

• Continuous output: 2,000 watts; Peak: 3,700 watts
• Ampere rating: 100 amps at 12 volts DC
• Input voltage: 9–16V DC (inverter); 60–140V AC (charger)
• Efficiency: 95 percent
• Operating temperature: -4°F to 140°F
• Modified sine waveform suitable for standard loads
• 60-amp transfer relay for automatic switchover
• Compact design with versatile mounting options
• ETL/cUL and CSA C22.2 No. 107.1-01 certified
• Limited 3-year warranty
