Specifications
| SKU | 10-1106 |
|---|---|
| Mfg # | 62115 |
| Brand | JR Products |
| Weight | 0.322 kg |
| Dimensions | 24.13 × 13.97 × 6.99 cm |
| Inlet Connection | City Water Female Threads |
| Mounting Type | Recessed Mount |
| Recess Depth | 2-1/2 Inch |
| Outlet Connection | 1/2 Inch Female Threads |
| Tank Vent | Without Vent |
| Cutout Size (IN) | 3-1/2 Inch Diameter |
Description
A recessed-mount water inlet for a cleaner, more integrated RV exterior finish. Metal housing seats 2-1/2 inches deep inside the wall cavity, with integrated brass check valve and 1/2-inch female thread outlet. Requires a larger 3-1/2-inch diameter cutout and suits installations where flush mounting is desired.
- Mounting: Recessed with metal housing
- Recess depth: 2-1/2″
- Outlet: 1/2″ female threads
- Cutout size: 3-1/2″ diameter
- Flange diameter: 4-5/8″
- Includes: Check valve and dust cover
