Specifications
| SKU | 07-5960 |
|---|---|
| Mfg # | 5023-BSS |
| Brand | Blue Sea Systems |
| Weight | 0.113 kg |
| Dimensions | 20.32 × 10.79 × 5.08 cm |
| Power Rating | 32 Volt DC/ 100 Ampere Per Block/ 30 Ampere Per Circuit |
| Type | Terminal Mount |
| Circuit Type | Four Circuits |
| Fuse Type | ATC/ ATO |
| Status Indicator Type | No Status Indicator |
| Cover Style | Protective Cover |
Description
This four-circuit fuse block mounts directly on the battery terminal stud for central power protection in RV electrical systems. Class T fuses provide fast-acting circuit protection for inverters and sensitive electronics.
Screw terminals secure incoming wires, and four nylon-insulated ring terminals are included. A protective cover shields contacts, and the compact design accepts small-format circuit labels for clear identification.
- Voltage: 32 Volt DC
- Power: 100 Ampere per block, 30 Ampere per circuit
- Circuits: 4
- Installation: Terminal mount on battery stud
- Fuse Type: Class T (ATC/ATO)
- Includes: Fuses, terminal rings, protective cover
