Specifications
| SKU | 03-3528 |
|---|---|
| Mfg # | 5046-BSS |
| Brand | Blue Sea Systems |
| Weight | 0.181 kg |
| Dimensions | 22.71 × 4.19 × 4.19 cm |
| Power Rating | 32 Volt/ 100 Ampere Per Block/ 30 Ampere Per Circuit |
| Type | Water Resistant |
| Circuit Type | 8 Circuit Positions |
| Fuse Type | ATC/ ATO |
| Status Indicator Type | No Status Indicator |
| Cover Style | Protective Cover |
Description
Water-resistant fuse protection for 8 circuits in demanding RV and marine environments. This surface-mount block meets ISO 8846 and SAE J1171 standards and handles exposure to salt spray and splash zones. The single-side design minimizes panel footprint whilst the protective cover meets ABYC/USCG insulation requirements.
Tin-plated copper buses and clips provide low-resistance connections, accepting ring or snap-fork terminals for flexible installation.
- 32 Volt / 100 Ampere per block, 30 Ampere per circuit
- 8 circuit positions
- Water-resistant construction
- ATC/ATO fuse compatibility
- Protective cover included
- Terminals included
